High round and oblong conical tank

These tanks vary in their degree of conicity, which ranges from 26% to 31%. They are thermally inert and so favour long, gentle fermentation.
Their design is modelled on traditional wooden vats but with modifications adapted to the needs of modern wine-makers. These designs have also been made for the Screaming Eagle, Dana Estate, and Harlan domaines.

Basic colors available
Blanc Coquille d'oeuf Gris anthracite Gris clair Gris moyen Lie de vin Noir Ocre rouge Pierre Vert d'eau
Contact us for any specific request

The different models
Units of measurement system : International Sytem

Modéle Volume Shape Conicity Upper Width Lower Width Upper Depth Lower Depth Height Weight
CPC 70 70 Round 26% 2,60 1,87 2,60 1,87 2,70 8,8
CPC 85 85 Oblong 26% 2,60 1,87 2,90 2,17 2,70 9,4
CPC 100 100 Oblong 26% 2,60 1,87 3,20 2,47 2,70 10,3
DANA 31 31 Round 26% 2.10 1.65 2.10 1.65 1.75 3.4
DANA 40 40 Oblong 26% 2.10 1.65 2.45 2.0 1.75 3.9
DANA 50 50 Oblong 26% 2.10 1.65 2.80 2.35 1.75 4.5
HRE 40 40 Round 26% 2.15 1.55 2.15 1.55 2.15 4
HRE 50 50 Oblong 26% 2,15 1,55 2,45 1,85 2,15 4,8
HRE 60 60 Oblong 26% 2,15 1,55 2,75 2,15 2,15 5,2
SE 30 30 Round 31% 2.03 1.48 2.03 1.48 2.03 3.4
SE 40 40 Oblong 31% 2.03 1.48 2.33 1.78 2.03 4.0
